Condenser rau Instrument Vaj Huam Sib Luag Lub condenser yog ib feem ntawm lub tub yees system thiab yog ib hom ntawm cov cua kub exchanger. Nws tuaj yeem hloov roj lossis vapor rau hauv cov kua, thiab hloov cov cua sov hauv lub raj mus rau huab cua ze ntawm lub raj hauv txoj kev ceev heev Tube Fin Condenser Standard tube-fin condenser coils ...
Hauj lwm lawm
Condenser rau Instrument Vaj Huam Sib Luag
Lub condenser yog ib feem ntawm lub tub yees system thiab yog ib hom ntawm tshav kub exchanger. Nws tuaj yeem hloov cov roj lossis vapor rau hauv cov kua, thiab hloov cov cua sov hauv lub raj mus rau huab cua ze ntawm lub raj hauv txoj kev ceev heev
Tube Fin Condenser
Standard tube-fin condenser coils muaj cov raj tooj liab mechanically bonded rau txhuas fins nrog louver enhancements. Qhov hla ntu qhia cov raj tooj liab thiab ob peb lub fins aluminium. High thermal efficiency yog tiav los ntawm kev sib cuag hlau ncaj qha ntawm cov hlab thiab cov fins. Fin louvers nce lub peev xwm hloov hluav taws xob ntawm cov fins. Yog li ntawd, qhov no coil tsim ua tau zoo dua thermal ua haujlwm.
Cov khoom no yog tsim rau kev sib dhos thiab kev hloov kho ntawm compressor cua sov dissipation, khoom siv hluav taws xob dissipation, lub computer dej txias, ntau yam cua txias, dej txias, tub yees, cua sov, cua sov dissipation, roj txias, thiab lwm yam. Nws kuj yog haum rau ntau yam kev hloov kho, thiab muaj ntau yam specifications thiab ntau thiab tsawg.
Daim ntawv pov thawj ntawm kev hwm
Lwm yam sib txawv ntawm evaporator / condenser
Khoom superiority
Factory tiag tua
Kev pabcuam
Ntim kev thauj mus los
Peb cov condensers / evaporators tuaj yeem siv rau hauv tub yees, lub freezers, cov rooj sib tham, cov khoom siv dej, cov dej txias.
Peb tuaj yeem muab cov khoom raws li cov neeg siv khoom kos duab lossis cov qauv.
Thov koj xav tiv tauj peb yog tias koj muaj kev xav tau.
Specification ntawm aluminium raj fin condenser
| Aluminium raj | Qhov deb | Kab nrug | Flating qhov siab ntawm fin |
| 7 | 21 | 12.7 | 1.6-2.4 |
| 7 | 21 | 18.2 | 1.5-4.5 |
| 9.52 | 25 | 21.65 | 1.8-5.7 |
Specification ntawm tooj liab raj fin evaporator & condenser
| Tsis muaj. | Lub raj tooj liab | Qhov deb | Kab nrug | Flating qhov siab ntawm fin |
| 1 | 5 | 19.05 | 16 | 1.5-5 |
| 2 | 5 | 21 | 18.2 | 1.5-5 |
| 3 | 6 | 25 | 21.65 | 1.4-6 |
| 6.35 | 25 | 21.65 | 1.4-6 | |
| 4 | 7 | 25 | 21.65 | 1.4-6.5 |
| 5 | 7 | 21 | 12.7 | 1.4-3 |
| 6 | 7 | 21 | 18.2 | 1.4-6.5 |
| 7 | 7 | 21.8 | 20 | 1.5-4.5 |
| 8 | 7.94(5/16) | 25 | 21.65 | 1.4-5 |
| 9 | 9.52(3/8) | 25 | 21.65 | 4.0-10 |
| 10 | 9.52(3/8) | 25.4 | 15.88 | 1.4-3 |
| 11 | 9.52(3/8) | 25 | 12.5 | 1.8-5 |
| 9.52(3/8) | 25 | 25 | 1.4-4 | |
| 12 | 9.52(3/8) | 35 | 35 | 5.0-10 |
| 13 | 12(7/16) | 35 | 35 | 6-8.5 |
| 14 | 12.7(1/2) | 31.75 | 27.5 | 6-8.5 |
